Honeywell Granit 1991 Standard Range - BT 1991ISR-3-R
Honeywell Granit 1991 Standard Range
MECHANICAL
Dimensions - Scanner (L x W x H): 192 mm x 76 mm x 100 mm (7.6 in x 3.0 inx 3.9 in)
Dimensions - Base (L x W x H): 245 mm x 102 mm x 60 mm (9.6 in x 4.0 in x 2.4 in)
Weight - Cordless: 405 g (14.3 oz)
WIRELESS
Rádio/Range: 2.4 GHz (ISM Band) Adaptive Frequency Hopping Bluetooth v4.2; Class 1: 100 m (330 ft) line of sight
POWER OPTIONS
Battery: 2450 mAh Li-ion minimum
Number of Scans: Up to 50,000 scans percharge
Expected Duration of Operation: 14 hodín (1 scan per second)
User Indicators: Good Decode LEDs,Beeper (adjustable tone and volume),Vibration (adjustable), Bluetooth®connectivity, Battery status
ELECTRICAL
Input Voltage: 4.0 VDC to 5.5 VDC
Operating Power - Cordless: 5 W (1000 mA @ 5 VDC)
Standby Power - Cordless (non-chargingpower): 0.6 W (120 mA @ 5 VDC)
Host System Interfaces: USB, Keyboard Wedge, RS-232 TTL
ENVIRONMENTAL
Operating Temperature*: -20°C až 50°C (-4°F až 122°F)
Storage Temperature: -40 °C až 70 °C (-40 °F až 158 °F)
Humidity: Up to 95% relatívnej humidity, non-condensing
Drop: 2 m (6.5 ft): 50 kvapiek od -30 °C do 50 °C (-22 °F do 122 °F), nekontrolovaný RH2.4 m (8 ft): 20 kvapiek pri 25 °C (77 °F) ),55% RH3 m (10 ft): MIL-STD-810G, 25°C (77°F),55% RH
Tumble: 7,000 1 m (3.3 ft) tumbles
Environmental Sealing - Scanner: IP67 a IP65
Environmental Sealing -Charge/Communication Base: IP51
Light Levels: 0 až 100,000 lux(9,290 foot-candles)
ESD: ±20 kV air discharge, ±8 kV contactdischarge
SCAN PERFORMANCE
Scan Pattern: Area Imager (1280 x 800pixel array)
Motion Tolerancia: Up to 4500 mm/s (177 in/s)
Scan Angle: Horizontal: 40°, Vertical: 30°Print Contrast: 20% minimum reflectance difference
Roll, Pitch, Skew: -360 °, 45 °, 65 °
Decode Capabilities: Reads štandard 1D,PDF, 2D, Postal, Digimarc, DOT Code and OCR symbologies
Warranty - Scanner: Three-year factory warranty
Warranty - Battery Pack: One-year factory warranty
Parametre
Hmotnosť | 0,438 kg |
---|
