SG3428XMPP
Omada 24-portový gigabitový a 4-portový 10GE SFP+ Managed switch L2+ so 16 portami PoE+ a 8 portami PoE++

Funkcia
*4× 10 Gb/s SFP+ sloty
*8× Gigabitové 802.af/at/bt PoE++ porty (Maximálny PoE rozpočet 90 W na každý port)
*16× Gigabitové 802.3af/at PoE+ porty (Maximálny rozpočet 30 W na každý port)
*Celkový PoE rozpočet 500 W
*Centralizovaná správa v cloude cez web alebo aplikáciu Omada†
*Samostatná správa cez web, CLI, SNMP a RMON
*Statické smerovanie, VLAN, ACL, QoS, IGMP Snooping, OAM a DDM
*ERPS podporuje rýchlu ochranu a obnovu v kruhovej topológii
*Odolné kovové puzdro a dizajn pre montáž do racku

Špecifikácia

Hardvér
Interface
*24× 10/100/1000 Mbps RJ45 Ports (8× PoE++, 16× PoE+)
*4× 10G SFP+ Slots
*1× RJ45 Console Port
*1× Micro-USB Console Port
Fan Quantity
*3
Physical Security Lock
*Yes
Power Supply
*100-240 V AC ~ 50/60 Hz
PoE Ports (RJ45)
*Štandard: 802.3at/af/bt compliant
*PoE++ Ports: Porty 1~8 (po 90 W PoE Output per Port)
*PoE+ Ports: Ports 9~24 (30 W PoE Output per Port)
*Power Budget: 500 W
Dimensions ( W x D x H )
*440×330×44 mm
Mounting
*Rack Mountable
Max Power Consumption
*605.5W (110V/60Hz) ( with 500W PD connected)
Max Heat Dissipation
*2064.96 BTU/hr (110 V/60 Hz) (s 500W PD connected)
Výkon
Switching Capacity
*128 Gbps
Packet Forwarding Rate
*95.23 Mpps
MAC Address Table
*16 K
Packet Buffer Memory
*12 Mbit
Jumbo Frame
*9 KB
Softvér
QoS, L2 a L2+ Features, L2 Multicast, Advanced Features, VLAN, Access Control List, Security, IPv6, MIBs
Pre viac informácií naštívte web výrobcu.
Management
Omada App
*Yes. Requiring use of Omada Hardvér Controller, Omada Cloud-Based Controller, alebo Omada Software Controller.
Centralized Management
*Omada Cloud-Based Controller
*Omada Hardware Controller
*Omada Software Controller
Cloud Access
*Yes. Requiring use of Omada Hardvér Controller, Omada Cloud-Based Controller, alebo Omada Software Controller.
Zero-Touch Provisioning
*Yes. Requiring use of Omada Cloud-Based Controller.
